Glo-Ball
F3021500

Glo-Ball Basic 1

Table lamp emitting diffused light. Features a diffuser made of externally acid-etched, hand-blown, flashed opaline glass with a die-cast aluminium, alodine-plated threaded ring nut. Base in 30% fibreglass-reinforced, injection-moulded polyamide. Diffuser support in painted, die-cast aluminium. Equipped with an electronic dimmer on the power cable for 0–100% light adjustment.

Halogen - 150W

Technical Drawing
Flos-Pim-Technical_Drawing-Luminaire-Table-Glo_Ball-Basic_1
Main specifications
EAN
8059607002360
Mounting
Environments
Light source type
Light sources included
No
Lamp category
Lamp holders
Ilcos
HSGS
Number of lamps
1
Power (W)
150
Schematic light drawing
F3021000WGLO-BALL_BASIC_1_150W-HL
Photometric
Lighting type
Light distribution
Extreme cut off
No
Electrical
Insulation class
Frequency (Hz)
50/60
Main voltage (Vac)
220-240
Dimmable
Dimming interface
Plug type
Batteries inside
No
Physical
Length (mm)
330
Cord colour
productFields.physical.cordLength
1900
Net weight (kg)
2.58
Package volume (m3)
0.07
IP internal

Download

Photometric Files

Technical Drawings
