FA50904306 GreyHeavy Metal Spot 2
Designed by FLOS Outdoor
LED source included. Electric remote 24V dc ON/OFF power supply to be ordered separately. Wall fixing bracket included. The luminaire is equipped with a protruding, neoprene, 250 mm cable and a wiring kit with crimp connectors and adhesive heat-shrink tubing guaranteeing the water tightness of the connection. Extra clear transparent glass.
5W - 389lm - 3000K - CRI> 80 - Beam° 14
Technical Drawing
Main specifications
EAN
8054793627977
Mounting
Wall
Enviroment
Outdoor wet location
LED type
Power LED
Power (W)
5
System power (W)
5.9
Source flux (lm)
466
System flux (lm)
389
Schematic light drawing
Photometric
Light distribution
Symmetric
CCT (K)
3000
CRI>
80
Beam angle C0-180 (º)
14
Beam angle C90-270 (º)
14
Extreme cut off
No
Electrical
Insulation class
III
Main voltage (Vac)
24
Driver
Remote excluded
Dimming type
Non Dimmable
Emergency type
No
Physical
Colour
Grey
Orientation
Adjustable
Longitudinal tilting (°)
180
Net weight (kg)
0.94
Package height (cm)
140
Package width (cm)
180
Package length (cm)
135
IP
65
Notes
Please check with your referent person in our Front Office if a code modification is needed to meet the required certification compliance'
Dimmable version on request
Photometric Files
Ecodesign and Energy Labelling
This product contains a light source of energy efficiency class F
