Decorative Ok
F4640030 Black

OK

Lamp providing direct light. Head in gloss varnished. Body in injection-stamped PA66+30%FV with cover in gloss varnished. Orientable head. The light fitting can be moved vertically by running the internal structure of the body on a steel cable tensioned between the ceiling and the floor (useful length 4000mm). Dimmable switch with Soft Touch technology. Adaptor on plug connector with interchangeable plugs.

18W - 1551lm - 2700K

Also available in:
Are you a professional and your project needs consulting and support?
An exclusive one-on-one service for our professional clients providing specialist support and advice.
BOOK AN APPOINTMENT
Technical Drawing
Main specifications
EAN
8059607005064
Mounting
Suspension
Enviroment
Indoor dry location
Light source type
LED
LED type
LED Module
Power (W)
18
System flux (lm)
1551
Schematic light drawing
Photometric
Light distribution
Symmetric
CCT (K)
2700
Extreme cut off
No
Electrical
Insulation class
III
Frequency (Hz)
50/60
Main voltage (Vac)
100-240
Driver
Remote included
Dimmable
Yes
Dimming type
Electronic 24V
Dimming interface
Dimmer Integrated
Plug type
Type A, Type C, Type G
Batteries inside
No
Physical
Colour
Black
Length (mm)
200
Cord colour
Black
Canopy colour
Black
Canopy dimension (mm)
64
Net weight (kg)
2.92
Package height (cm)
140
Package width (cm)
340
Package length (cm)
390
Package volume (m3)
0.02
IP
20
CE
CMIM Morocco
EAC
RETILAP
UKCA
USA
20
IK04 - 0.50 Joule
IK04 - 0.50 Joule
20

Ecodesign and Energy Labelling

This product contains a light source of energy efficiency class F

REPLACEABLE2 Replaceable (LED only) light source by a professional

PWRSUPRPL3 Replaceable control gear by an end-user

Spare Parts
