Stylos

Floor lamp emitting indirect and diffused light. Silver powder-coated steel base with opaline extruded polymethylmethacrylate (PMMA) diffuser column. on/off control of the two light sources located at either end of the column and managed via a double foot switch on the power cable.

Designed by Achille Castiglioni in 1984, Stylos turns a vertical column of light into a sculptural presence. It may appear simple, but every detail is deliberate, down to a weighted base that prevents tipping. Castiglioni famously drew inspiration from everyday materials and championed a ‘less is more’ philosophy that is evident in his work, which uses minimal elements to create larger-than-life designs. Stylos is a luminous totem that quietly transforms its surroundings.

Halogen - 2 x 105W

Technical Drawing
Flos-Pim-Technical_Drawing-Luminaire-Floor-Stylos
Main specifications
Mounting
Floor
Environments
Indoor dry location
Light source type
Bulb
Light sources included
No
Lamp category
Halogen
Lamp holders
E27
Ilcos
HSGSA/W + IPAR
Number of lamps
2
Power (W)
105
Schematic light drawing
F6310004WSTYLOS_120-150W-INC
Photometric
Lighting type
Total
Light distribution
Symmetric
Extreme cut off
No
Electrical
Insulation class
I
Frequency (Hz)
50/60
Main voltage (Vac)
220-250
Dimmable
No
Dimming interface
Switch Integrated (Not Dimmable)
Plug type
Type I
Batteries inside
No
Physical
Length (mm)
170
Cord colour
Black
Cord length (mm)
2850
Net weight (kg)
9.85
Package volume (m3)
0.15
IP internal
20
IECEC
Autoprotected Lamp
20
IK00 - 0.00 Joule
