Architectural TheBlockofLight
09.3310.01C Matte White

Theblockoflight

Semi-recessed signalling lamp for indoor or outdoor use. Non-regulable 100-240V, 50-60Hz power supply and 500 mm power cable included.

LED - Power LED - 2.2W - 85lm - 3000K - CRI> 80 - Beam° 45

Are you a professional and your project needs consulting and support?
An exclusive one-on-one service for our professional clients providing specialist support and advice.
BOOK AN APPOINTMENT
Technical Drawing
Main specifications
Mounting
Wall recessed
Enviroment
Indoor dry location, Outdoor wet location
Light source type
LED
LED type
Power LED
Lamp category
LED
Power (W)
2.2
Source flux (lm)
296
System flux (lm)
85
Schematic light drawing
Photometric
Lighting type
Indirect, Direct
Light distribution
Asymmetric
CCT (K)
3000
CRI>
80
Beam angle C0-180 (º)
45
Beam angle C90-270 (º)
57
UGRL
<19
Electrical
Insulation class
I
Frequency (Hz)
50/60
Driver
Integrated
Dimmable
No
Dimming type
Non Dimmable
Emergency type
No
Physical
Colour
Matte White
Trim
No
Orientation
Fixed
Recessed depth (mm)
47
Length (mm)
75
Net weight (kg)
0.4
IP
65
EAC
CE
RETILAP
UKCA
03 - Italy
03 - Italy
USA
Gwt 850 (º)
65
65

Accessories & Power Supply

optional (1)
