Infra-StructureData Connection Rod Rose Ø 140 mm
Designed by Vincent Van Duysen, 2018
Data connection rod rose ø140mm. Use one for each line of the installation, for connection to DALI or 1-10V signal source. Adjustable 25 mm, to adapt it to irregular ceilings.
Length: 400 - Ceiling surface
Technical Drawing
Main specifications
Mounting
Environments
Light sources included
no
Electrical
Power supply
Power supply type
, ,
Emergency
No
Physical
Colour
Trim
No
Length (mm)
400
Net weight (kg)
0.89
IP internal
IP external
Notes
The closure terminals will also be electrified and must be ordered separately. Data connection rod rose ø140 mm: Use one for each line of the installation, for connection to DALI or 1-10V signal source. Adjustable 25 mm, to adapt it to irregular ceilings.
