Light ShadowLight Shadow Pro Ø 60 Fixed Optic Medium
Designed by FLOS Architectural, 2022
LED lighting module, with low glare, to be inserted in the recessed frames (not included), installation through a bayonet system with interchangeable spots. Remote driver not included.
15W - 1109lm - 2700K - CRI> 90 - Beam° 24
Technical Drawing
Main specifications
Mounting
Environments
Light source type
Light sources included
Yes
LED type
Number of lamps
1
Power (W)
15
Source flux (lm)
1402
Lumen Output (lm)
1109
Efficacy (lm/W)
74
Schematic light drawing
Photometric
Lighting type
Light distribution
CCT (K)
CRI>
McAdam steps (SDCM)
2
Rf fidelity index
93
Rg gamut index
99
LED Life / Failure Ratio
L70B40 > 50.000h (Tc=85ºC)
Beam angle C0-180 (º)
24
Beam angle C90-270 (º)
24
Extreme cut off
Yes
UGRL
<10
Electrical
Insulation class
Forward voltage (V)
35.9
LED current (mA)
400
Power supply
Dimmable
Power supply type
, , , , , ,
Physical
Colour
Orientation
Spot diameter (mm)
60
Net weight (kg)
0.22
Package height (mm)
157
Package width (mm)
210
Package length (mm)
135
IP internal
IP external
Notes
Please select 250 mA setting in the remote driver to match the power of the Adjustable version.
