60.9768

Non dimmable continuous current power supply of 220/240V - 50/60Hz with power current selected through adjustable with DIP-switch 350 mA - 7,3W / 400mA - 8,4W / 450 mA - 9,4W / 500 mA - 10,5W

Non dimmable continuous current power supply of 220/240V - 50/60Hz with power current selected through adjustable with DIP-switch 350 mA - 7,35W / 400mA - 8,4W / 450 mA - 9,45W / 500 mA - 10,5W

Are you a professional and your project needs consulting and support?
An exclusive one-on-one service for our professional clients providing specialist support and advice.
BOOK AN APPOINTMENT
Technical Drawing
Main specifications
EAN
4062172199308
Enviroment
Indoor dry location
Power (W)
10.5
System power (W)
12.2
Photometric
Extreme cut off
No
Electrical
Insulation class
II
Frequency (Hz)
50-60
Main voltage (Vac)
220-240
Driver output voltage (V)
11-21
Forward voltage (V)
11
LED current (mA)
350 / 400 / 450 / 500
Dimmable
No
Dimming type
Non Dimmable
Precabled
No
Physical
Length (mm)
104
Net weight (kg)
0.06
IP
20
EAC
CE
UKCA
CCC
03 - Italy
03 - Italy
20
20

Ecodesign and Energy Labelling

PWRSUPRPL2 Replaceable control gear by a professional
