Atom 200

LED accent lighting module to be installed in the Zero Track system.

Download Documentation

Innovative 24V system composed of a miniaturized track that subtly adapts to the surface offering a variety of dimmable luminaries.

(20)

Power (W)

Lumen Output (lm)

CCT (K)

Colour

Code	Name	Power (W)	Lumen Output (lm)	CCT (K)	CRI>	Beam angle (º)	Dimming Type	Mounting
09.3951.CZ	Atom 200 Casambi integrated	10.5	395	2700	90	110	Dimmable Casambi	Track
09.3951.40	Atom 200 Casambi integrated	10.5	395	2700	90	110	Dimmable Casambi	Track
09.3951.18	Atom 200 Casambi integrated	10.5	395	2700	90	110	Dimmable Casambi	Track
09.3951.14	Atom 200 Casambi integrated	10.5	395	2700	90	110	Dimmable Casambi	Track
09.3951.05	Atom 200 Casambi integrated	10.5	395	2700	90	110	Dimmable Casambi	Track
09.3950.CZ	Atom 200 Casambi integrated	10.5	424	3000	90	110	Dimmable Casambi	Track
09.3950.40	Atom 200 Casambi integrated	10.5	424	3000	90	110	Dimmable Casambi	Track
09.3950.18	Atom 200 Casambi integrated	10.5	424	3000	90	110	Dimmable Casambi	Track
09.3950.14	Atom 200 Casambi integrated	10.5	424	3000	90	110	Dimmable Casambi	Track
09.3950.05	Atom 200 Casambi integrated	10.5	424	3000	90	110	Dimmable Casambi	Track
09.3851.CZ	Atom 200	10.5	395	2700	90	110	Non Dimmable	Track
09.3851.40	Atom 200	10.5	395	2700	90	110	Non Dimmable	Track
09.3851.18	Atom 200	10.5	395	2700	90	110	Non Dimmable	Track
09.3851.14	Atom 200	10.5	395	2700	90	110	Non Dimmable	Track
09.3851.05	Atom 200	10.5	395	2700	90	110	Non Dimmable	Track
09.3850.CZ	Atom 200	10.5	424	3000	90	110	Non Dimmable	Track
09.3850.40	Atom 200	10.5	424	3000	90	110	Non Dimmable	Track
09.3850.18	Atom 200	10.5	424	3000	90	110	Non Dimmable	Track
09.3850.14	Atom 200	10.5	424	3000	90	110	Non Dimmable	Track
09.3850.05	Atom 200	10.5	424	3000	90	110	Non Dimmable	Track
