Superarchimoon outdoor Panama
Designed by Philippe Starck, 2000
Floor lamp emitting direct and diffused light. External diffuser in pleated fabric with internal diffuser in acid-etched, hand-blown glass. Diffuser support in sand-cast aluminium. Structure composed of painted tubular aluminium arms and tie rods, stainless steel spring and die-cast aluminium joints. Sand-cast aluminium base with six lead counterweights and spun aluminium base cover. Fabric-covered power cord with electronic dimmer for 0–100% light adjustment.
250W - Beam° 78
Also available in:
Technical Drawing
Main specifications
EAN
8059607006313
Mounting
Light source type
Light sources included
No
Lamp holders
Ilcos
HSGS
Number of lamps
1
Power (W)
250
Schematic light drawing
Photometric
Lighting type
Light distribution
Beam angle C0-180 (º)
78
Beam angle C90-270 (º)
78
Electrical
Insulation class
Frequency (Hz)
50/60
Main voltage (Vac)
220-240
Dimmable
Dimming interface
Plug type
Emergency
No
Batteries inside
No
Charging min time
NO
Physical
Colour
Orientation
Length (mm)
790
Net weight (kg)
160.3
Package volume (m3)
1.46
IP internal
Notes
Light source not included. HSGS E27: 1x250W or 1 LED: 21W - 2450 lm - 3000K
We recommend using a connection system with a degree of protection greater than or equal to the degree of protection of the luminaire.
Bulbs
Spare Parts
03. Superachimoon Outdoor Cover
RF6376200
04. Superarchimoon Floor support bag kit
RF6372200
