Systems The Micro Running Magnet

Light Stripe Diffused

Designed by FLOS Architectural

Diffused LED light module to be installed in The Micro Running Magnet System.

Download Documentation

Product highlight

Ultra-miniaturized luminous objects

Innovative program of ultra-miniaturized structures in recessed and surface versions

Discover the Story

P_Md_F-The-Micro-Running-Magnet-Light-Stripe-Diffused-Flos-Architectural-highlight.jpg

Luminaire

(16)

Power (W)

Lumen Output (lm)

CCT (K)

	Code	Name	Power (W)	Lumen Output (lm)	CCT (K)	CRI>	Beam angle (º)	Dimming Type	Mounting
	03.2275.14	Light Stripe Diffused	18	904	5000	90	114	Non Dimmable, Dimmable	Track
	03.2274.14	Light Stripe Diffused	18	947	4000	90	114	Non Dimmable, Dimmable	Track
	03.2273.14	Light Stripe Diffused	18	919	3000	90	114	Non Dimmable, Dimmable	Track
	03.2272.14	Light Stripe Diffused	18	821	2700	90	114	Non Dimmable, Dimmable	Track
	03.2271.14	Light Stripe Diffused	13.5	678	5000	90	114	Non Dimmable, Dimmable	Track
	03.2270.14	Light Stripe Diffused	13.5	710	4000	90	114	Non Dimmable, Dimmable	Track
	03.2269.14	Light Stripe Diffused	13.5	689	3000	90	114	Non Dimmable, Dimmable	Track
	03.2268.14	Light Stripe Diffused	13.5	616	2700	90	114	Non Dimmable, Dimmable	Track
	03.2267.14	Light Stripe Diffused	9	452	5000	90	114	Non Dimmable, Dimmable	Track
	03.2266.14	Light Stripe Diffused	9	473	4000	90	114	Non Dimmable, Dimmable	Track
	03.2265.14	Light Stripe Diffused	9	460	3000	90	114	Non Dimmable, Dimmable	Track
	03.2264.14	Light Stripe Diffused	9	411	2700	90	114	Non Dimmable, Dimmable	Track
	03.2263.14	Light Stripe Diffused	4.5	226	5000	90	114	Non Dimmable, Dimmable	Track
	03.2262.14	Light Stripe Diffused	4.5	237	4000	90	114	Non Dimmable, Dimmable	Track
	03.2261.14	Light Stripe Diffused	4.5	230	3000	90	114	Non Dimmable, Dimmable	Track
	03.2260.14	Light Stripe Diffused	4.5	205	2700	90	114	Non Dimmable, Dimmable	Track

The Micro Running Magnet - Profiles

(2)


The Micro Running Magnet Surface14 products


The Micro Running Magnet Recessed7 products

Recessed Installation

Surface Installation

Product_Specification_MICRO_RUNING-recessed-01

Compose your The Micro Running Magnet according to your needs

Have a look at this scheme for a quick product overview.

Product_Specification_MICRO_RUNING-surface-01

Compose your The Micro Running Magnet according to your needs

Have a look at this scheme for a quick product overview.

The Micro Running Magnet - Other Light Modules

(7)

P_Md_E-The-Micro-Running-Magnet-Light-Stripe-Wall-Washer-Flos-Architectural-still-life.jpg

Light Stripe Wall-Washer16 products


Nano Spot16 products


Micro Spot24 products


Light Shadow Spot32 products


Spot16 products


Find Me 08 products


Find Me 18 products

Part of


The Micro Running Magnet
