Related to

Spot

Accent lighting LED module to be installed in The Running Magnet System. Built-in DC/DC electronic voltage converter.

Download Documentation

Innovative program of ultra-miniaturized structures in recessed and surface versions.

(16)

Optical Type

Lumen Output (lm)

CCT (K)

Colour

Code	Name	Power (W)	Lumen Output (lm)	CCT (K)	CRI>	Beam angle (º)	Dimming Type	Mounting
03.2238.40A	Spot	6	356	5000	90	20	Non Dimmable, Dimmable	Track
03.2238.14A	Spot	6	356	5000	90	20	Non Dimmable, Dimmable	Track
03.2237.40A	Spot	6	342	4000	90	20	Non Dimmable, Dimmable	Track
03.2237.14A	Spot	6	342	4000	90	20	Non Dimmable, Dimmable	Track
03.2236.40A	Spot	6	301	3000	90	20	Non Dimmable, Dimmable	Track
03.2236.14A	Spot	6	301	3000	90	20	Non Dimmable, Dimmable	Track
03.2235.40A	Spot	6	315	2700	90	20	Non Dimmable, Dimmable	Track
03.2235.14A	Spot	6	315	2700	90	20	Non Dimmable, Dimmable	Track
03.2233.40A	Spot	6	384	5000	90	13	Non Dimmable, Dimmable	Track
03.2233.14A	Spot	6	384	5000	90	13	Non Dimmable, Dimmable	Track
03.2232.40A	Spot	6	369	4000	90	13	Non Dimmable, Dimmable	Track
03.2232.14A	Spot	6	369	4000	90	13	Non Dimmable, Dimmable	Track
03.2231.40A	Spot	6	324	3000	90	13	Non Dimmable, Dimmable	Track
03.2231.14A	Spot	6	324	3000	90	13	Non Dimmable, Dimmable	Track
03.2230.40A	Spot	6	340	2700	90	13	Non Dimmable, Dimmable	Track
03.2230.14A	Spot	6	340	2700	90	13	Non Dimmable, Dimmable	Track
