Systems The Micro Running Magnet

Light Stripe Wall-Washer

Designed by FLOS Architectural

Asymmetric wall-washer LED light module to be installed in The Micro Running Magnet System.

Download Documentation

P_Md_F-The-Micro-Running-Magnet-Light-Stripe-Wall-Washer-Flos-Architectural-highlight.jpg

Ultra-miniaturized luminous objects

Innovative program of ultra-miniaturized structures in recessed and surface versions

Discover the Story

P_Md_F-The-Micro-Running-Magnet-Light-Stripe-Wall-Washer-Flos-Architectural-highlight.jpg

Luminaire

(16)

Power (W)

Lumen Output (lm)

CCT (K)

	Code	Name	Power (W)	Lumen Output (lm)	CCT (K)	CRI>	Beam angle (º)	Dimming Type	Mounting
	03.2295.14	Light Stripe Wall-Washer	18	815	5000	90	114	Non Dimmable, Dimmable	Track
	03.2294.14	Light Stripe Wall-Washer	18	853	4000	90	114	Non Dimmable, Dimmable	Track
	03.2293.14	Light Stripe Wall-Washer	18	829	3000	90	114	Non Dimmable, Dimmable	Track
	03.2292.14	Light Stripe Wall-Washer	18	740	2700	90	114	Non Dimmable, Dimmable	Track
	03.2291.14	Light Stripe Wall-Washer	13.5	611	5000	90	114	Non Dimmable, Dimmable	Track
	03.2290.14	Light Stripe Wall-Washer	13.5	640	4000	90	114	Non Dimmable, Dimmable	Track
	03.2289.14	Light Stripe Wall-Washer	13.5	621	3000	90	114	Non Dimmable, Dimmable	Track
	03.2288.14	Light Stripe Wall-Washer	13.5	555	2700	90	114	Non Dimmable, Dimmable	Track
	03.2287.14	Light Stripe Wall-Washer	9	408	5000	90	114	Non Dimmable, Dimmable	Track
	03.2286.14	Light Stripe Wall-Washer	9	427	4000	90	114	Non Dimmable, Dimmable	Track
	03.2285.14	Light Stripe Wall-Washer	9	414	3000	90	114	Non Dimmable, Dimmable	Track
	03.2284.14	Light Stripe Wall-Washer	9	370	2700	90	114	Non Dimmable, Dimmable	Track
	03.2283.14	Light Stripe Wall-Washer	4.5	204	5000	90	114	Non Dimmable, Dimmable	Track
	03.2282.14	Light Stripe Wall-Washer	4.5	213	4000	90	114	Non Dimmable, Dimmable	Track
	03.2281.14	Light Stripe Wall-Washer	4.5	207	3000	90	114	Non Dimmable, Dimmable	Track
	03.2280.14	Light Stripe Wall-Washer	4.5	185	2700	90	114	Non Dimmable, Dimmable	Track

The Micro Running Magnet - Profiles

(2)


The Micro Running Magnet Surface14 products


The Micro Running Magnet Recessed7 products

Recessed Installation

Surface Installation

Product_Specification_MICRO_RUNING-recessed-01

Compose your The Micro Running Magnet according to your needs

Have a look at this scheme for a quick product overview.

Product_Specification_MICRO_RUNING-surface-01

Compose your The Micro Running Magnet according to your needs

Have a look at this scheme for a quick product overview.
